Dynamite Dux ? Sega 1989 You will need following:
Original game ? find on emunova.net
An Amiga or WINUAE
Action Replay or ROM image
Pencil and paper
one blank disk
The boot block crack can be downloaded in top of this page.
Just install it on a fresh copy of game ($ 0 ? 400) and it?s cracked.
Start by making a copy of original game disk. An error is present on track 0, probably a good old RNC.
When copy of game is run, it loads for a while and then it hangs short after. This is the protection kicking in.
Boot original game and enter AR when you hear the drive grinding sound of the copylock routine kicking in.
Copylocks start with the opcodes ? 48 7A ?, search for them: ? F 48 7A ?. AR returns no less than six addresses.
This old game actually has three copylock routines. They are all identical, so they can be cracked the same way.
Disassemble start of the first copylock and hold enter down, till the encrypted code stops. First copylock ends around address B64C. The code after compares the copylock key in D0 with address C744. If it fails, then game will hang.
Stick a break point to address B652 and exit AR: ? BS B652 ?. When end of protection is reached, AR will pop up and we can read the key from D0. ? You could also just grab it from address C744 if you don?t have the original…
When AR pops up, press ? R ? to see registers. Key is stored in D0.
Let?s have a little look at the code before the copylock routine:
The code where A6 is moved to stack, have to be removed or Amiga will crash when the patched copylocks is executed.
A memory address is also moved to A6, see contents of this address: M B09A. Copylock key is also returned here.
We?ll crack these three old copylocks, by wire the key into D0, 24 & (A6), then branch past the encrypted code and directly to the compare routine.
Let?s have a look at the copylock:
The first copylock routine starts at address B110. We will start patch at address B116, the same location in each of the three copylocks. The branch address will then be B654, start of the compare routine, right after the copylock.
It?s also important to NOP out the first line of code in each routine ( MOVE.L A6,-(A7) ) or Amiga will crash.
Insert copy of game and read a chump of the disk into memory, starting at address 10000: ? RT 40 50 10000 ? Find start and end address of the three copylocks and patch them:
Write tracks back: ? WT 40 50 10000 ?
If you prefer patching the whole potection from boot block, rather than changing tracks, do as follows: Read track 0 to address 70000; RT 0 1 70000.
Assemble 70056 (where game jumps to loader) and insert following, which will copy a crack patch from offset $ 100 on disk, to memory address 100 and take over game, so it calls the patch: 70056; MOVEM.L D0-D7/A0-A6,-(A7); 70056-70072; copy patch to address 100 7005A; LEA 100,A0 70060; LEA 70100(PC),A1 70064; MOVE.W #AC,D7 70068; MOVE.B (A1)+,(A0)+ 7006A; DBF D7,70068 7006E; MOVEM.L (A7)+,D0-D7/A0-A6 70072; MOVE.L #4EF90000,70074; 70072-70084; take over game , make it call crack 7007C; MOVE.W #100,70078 70084; JMP 70020; jump we took over Assemble 70100 and make the crack patch itself. This will crack the three copylocks, by moving following patch over them; ; NOP ; original code, not changed ; move.l key,d0 ;move.l d0,24.s ;move.l d0,(a6) ; bra past copylock 70100; MOVE.W #4E71,B110; 70100-7013A; move new opcodes into copylock 1 70108; MOVE.W B110,C80E 70112; MOVE.W B110,CE24 7011C; MOVE.L #203C8488,B116 70126; MOVE.L #FF421C0,B11A 70130; MOVE.L #242C80,B11E 7013A; MOVE.L #60000530,B122 70144; MOVE.L B116,C814; 70144-7018a; copy opcodes from copylock 1 to copylock 2 & 3 7014E; MOVE.L B11A,C818 70158; MOVE.L B11E,C81C 70162; MOVE.L B122,C820 7016C; MOVE.L B116,CE2A 70176; MOVE.L B11A,CE2E 70180; MOVE.L B11E,CE32 7018A; MOVE.L B122,CE36 70194; MOVE.L #4EF90000,70074; restore jump we too over 7019E; MOVE.W #B020,70078; restore jump we took over 701A6; MOVE.W #F0F,DFF180; trainer starts here, flash screen and wait mouse 701AE; MOVE.W #F,DFF180 701B6; BTST #6,BFE001 701BE; BEQ 701CC 701C0; BTST #A,DFF016 701C8; BEQ 7020A 701CA; BRA 701A6 701CC; NOP; will appear at address 1CC 701CE; NOP 701D0; MOVE.L 1CC.S,10E5A; train lives 701D8; MOVE.W 1CC.S,10E5E 701E0; MOVE.L 1CC.S,201EA 701E8; MOVE.W 1CC.S,201EE 701F0; MOVE.L #4EB80210,1FEC0; hook call to toggle function ? energy on/off 701FA; MOVE.L 1CC.S,1122E; train energy 70202; MOVE.W 1CC.S,11232 7020A; JMP B020; jump we took over 70210; MOVE.W #3213,D0; restore code removed at 1FEC0; this will appear at address 210 70214; BTST #A,DFF016; check RMB during game play, if pressed, branch to 70220 and toggle energy 7021C; BEQ 70220 7021E; RTS 70220; EORI.L #DF484E71,1122E; toggle energy 7022A; EORI.W #88DB,11232; toggle energy 70232; MOVE.W #FF,C0.S; delay 70238; ADDQ.W #2,C0.S 7023C; SUBQ.W #1,C0.S 70240; BNE 70238 70242; RTS When screen flashes, press LMB for unlimited lives & energy or RMB for normal game. During game play, press RMB to toggle energy on/off. Game will halt VERY shortly, to indicate your selection.
Correct boot block checksum: BOOTCHK 70000. Write back: WT 0 1 70000.
